#SA107A54526A - Sanwa PGS-CX2 Servo

SSL Compatible

- Compatible with CODE10 (M12S (RS), Exzes ZZ, MT-44)
Not compatible with CODE5 (M12, Exzes Z, MT-4S, MT-4, MT-S)
- MULTI SETTING GEAR compatible
Not compatible with PGS SETTING GEAR
- SSR mode compatible
- SHR mode compatible
- Lipo 2 cell battery compatible
- High torque type
- Coreless motor
- Metal Gears
- AL Heat Sink

Programmable Servo to be compatible with SSL & Telemetry - Setting Adjustment by wireless from Radio  - Setting Adjustment to connect Servo with Multi Setting Gear - Regarding Temperature, Current, Voltage and Volume Position on Servo inside,  Telemetry-transmission can be passed to Radio. # Initial Setting on Multi Setting Gear is necessary.

- Setting Items - SSL-CH (SSL Channel Setting) - STRETC (Stretcher Adjustment) - BOOST (BOOST Adjustment) - D-Band (Dead Band Adjustment) - MV-MID (Middle Torque Adjustment)  - MV-END (Later Torque Adjustment) - BREAK (Break Adjustment)  ?MV-HOLD (Power Adjustment at whole area) ?MV-FRQ (Feeling Adjustment at whole area)  ?MAX-PW (MAX Duty Adjustment)  - Multi Setting Gear is necessary for setting.

Speed  0.11 sec / 60° (7.4 V)  0.13 sec / 60° (6.0 V)

Torque  26.5 kg ·cm (7.4 V)  23.3 kg ·cm (6.0 V)

Dimensions  40.5 X 20.5 X 37.2 mm

Weight  59 g
