#HW30401862 - HOBBYWING XERUN BANDIT 17.5T BLACK G4R MOTOR

FEATURES

• Excellent performance, specially designed for 1/10 outlaw stock racing.
• The innovative outer diameter structure of fully exposed stator core maximizes the heat dissipation area and the end of the motor is a big opening structure to further improve the heat dissipation effect.
• Dual sensor interface design to meet various wiring/layout requirements.
• The special copper bar is customized and the spacing of copper bar is widened, which greatly facilitates the operation of soldering wire.
• The built-in high precision Hall sensor combined with the high precision and balanced rotor guarantee outstanding linearity of the motor.
• The use of high-performance stator core, 220? high-temperature-resistant enameled wire high precision and high strength bearings, and copper solder tabs with super current endurance guarantees outstanding performance and super durability.

SPECIFICATIONS

Scale: 1/10th Brushed/Brushless: BL

Sensored/Sensorless: SD

Pole Count: 2

KV Rating: 2500KV

LiPo Cells: 1-3S No-load

Current(A): 4.5A

O.D.(mm): 35.8

Length (mm): 53.9

Shaft Diameter (mm): 3.175

Weight (g): 190g

Front Bearing: D9*D4*T4

Rear Bearing: D8*D3*T4

ESC: XERUN XR10 PRO G3

Vehicles: 1/10th Outlaw Stock Racing
